EK430F/ EK430S/ EK430L
Horizontal operating table：Intuitive operation of standard 19 inch horizontal operating table
Ergonomic design, easy to learn and operate, high affinity and clear and concise human-machine interface
Detail
|
Project |
Unit |
EK430F |
EK430S |
EK430L |
|
|---|---|---|---|---|---|
|
X. Y and Z-axis travel |
mm |
400×300×220 |
|
||
|
U. V-axis trave |
mm |
60×60 |
|
||
|
Maximum workpiece size [width x depth x height] |
mm |
725×600×215 |
|
||
|
Maximum workpiece weight |
kg |
500 |
350 |
|
|
|
X. Y feed rate |
mm/min |
max.800 |
max.1800 |
|
|
|
Motor System |
asis |
X·Y·U·V·ZAxis AC servo motor |
X·YAxial motor/U · V · Z-axis AC servo motor |
|
|
|
Wire diameter (standard) |
mm |
∅0.15-0.3(0.25) |
|
||
|
Line tension |
gf |
300-2500 |
|
||
|
Maximum cutting slope (°)/workpiece thickness |
- |
±14.5/80mm（Wide angle nozzle DA+DB=15mm） |
|
||
|
Mechanical net weight (for water containing systems) |
kg |
2600 |
2850 |
|
|
|
Processing fluid power system device |
|
|
|
||
|
Filtering capacity |
|
340 |
650 |
|
|
|
Filtering method |
- |
Paper |
|
||
|
water quality control |
|
Auto |
|
||
|
Liquid temperature control |
- |
Auto |
|
||
|
Processing power supply |
|
|
|
||
|
LOOP MODE |
- |
Power MOS Transistor |
|
||
|
maximum output current |
A |
25 |
|
||
|
Set Units |
mm |
0.001 |
|
||
|
Maximum instruction value |
mm |
±9999.999 |
|
||
|
Appearance dimensions [width x depth x height] |
mm |
2203×2015×2435 |
|
||
|
Input power supply |
|
3-phase 220V±5% 50/60Hz±1Hz |
|
||
